chain link temporary fence

Our chain link temporary fence for construction can secure any site perimeter with cost-effective active solutions for controlled security and keeping the general public at a safe distance while continuing any event build program in safety. Temporary Fence Panels in the United States standard available various dimensions to meet any level security required, a brace of chain link fence constructions fence available cross, vertical only as well horizontal only etc., Tubing welding with vertical temporary fence posting is entirely cut in an ARC shape so that horizontal pipe can correspond to each tubing perfectly, as a standard 6'x12' and 8'x12' good appealing with United States local market for more about 6'x12' temporary fence, please find out more information from

Application chain link temporary fence

Residential and commercial building
harsh environments, remote and extreme climates
construction, events, civil, demolition, mining, government
Event security improved and pet run etc

Specifications

chain link temporary fence /Construction Fence Panels Spec
Tubing	1¼"(32mm) 1⅜"(35mm) 1½"(38mm) 1⅗"(40mm) 1⅝"(42mm) 1⅞"(48mm)and so on
Thickness of Tubing	14ga/2.00mm 14.5ga/1.90mm 15ga/1.80mm 15.5ga/1.70mm 16ga /1.6mm 16.5ga/1.50mm 17ga1.42mm 18ga 1.22mm
Chain mesh aperture	2"x2"/(50mm x 50mm) 2¼"x2¼"(57mmx57mm) 2⅜"x2⅜"(60mmx60mm) 2½"x2½"(63mmx63mm)
Height	4ft/1220mm 6ft/1820mm 8ft/2420mm
Width	12ft /3650mm was wide acceptance by the market also 8ft 9ft, 10ft 14ft
Panels Size	6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
Diameter /Gauge	10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
Base Optional 1	36" length x 30" width x 8"Height /914mmx762mmx203mm
Base Optional 2	36" length x 16" width x 8" Height /914mmx406mmx203mm
Base Optional 3	30" length x 18" width x 8" Height /762mm x460mm x203mm
Standard	ASTM A392-06
Steel	Galvanized Steel Construction
Finish	Corrosion-Resistant Zinc Coating
Transport Packing	Metal pallet Wrapped with Plastic
HDG zinc thickness	14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM

Parameters

Temporary Chain Link Fence /Construction Fence Panels Spec
Tubing	1¼”(32mm) 1⅜”(35mm) 1½”(38mm) 1⅗”(40mm) 1⅝”(42mm) 1⅞”(48mm)and so on
Thickness of Tubing	16GA/ 1.6mm thick as a standard or customized owned size
Chain mesh aperture	2”x2/”(50mm x 50mm) 2¼”x2¼”(57mmx57mm) 2⅜x2⅜(60mmx60mm) 2½”x2½” (63mmx63mm)
Height	4ft/1220mm 6ft/1820mm 8ft/2420mm
Width	12ft /3650mm was wide acceptance by the market also 8ft 9ft, 10ft 14ft
Panels Size	6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
Diameter /Gauge	10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
Base Optional 1	36” length x 30” width x 8” Height /914mmx762mmx203mm
Base Optional 2	36” length x 16” width x 8” Height /914mmx406mmx203mm
Base Optional 3	30” length x 18” width x 8” Height /762mm x460mm x203mm
Standard	ASTM A392-06
Steel	Galvanized Steel Construction
Finish	Corrosion-Resistant Zinc Coating
Transport Packing	Metal pallet Wrapped with Plastic
HDG zinc thickness	14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM
