anti-Climb 358 Security Fence
Feature of anti-climb clear-VU 358 security fence panels as follows；358 security fence is also called an anti-climb fence; the ultimate heavy-duty welded mesh panel provided the highest degree of security with excellent see-through visibility.
- High-security level than others such as chain link mesh
- Expensive compared to another type of offense due to a heavy-duty weight
- Challenging to move even use tools
- Deterrent matched up with razor and barb wire
Materials Of 358 Fence clearly
- low carbon steel wire
- Q235
- Q195
Finished 358 security mesh fence panels
- Hot dipped galvanized
- Pre-galvanized
- Pre-galvanized then powder coated RAL color
Applications of anti-cut climb 358 mesh
- 358 security fence for Public buildings
- factories and workshops
- schools, parks, and playground
- sports stadium,
- road and railways
- villa
Specification
358 security fence has toe and finger proof profile. With a spacing specification of 75mm x 12.5mm, fingers and toes can't go through. Our 358 security fence is perfect as a guarded fence system because its entire thickness, anti-cutting materials, and framework are incredibly resistant and hard to uninstall. With our excellent anti-climb fence supply, clients can enjoy the most outstanding relaxation and secured protection from the inside of their own.
Panel-type A (2D view)
| Mesh | Wire thickness | Surface Treatment | Panel width | Height |
| 76.2x12.7mm |
Horizontal wire:3.0,3.5,4.0mm Vertical wire:4.0mm |
Galvanized & Electrostatic polyester powder coated or hot-dipped galvanized. |
2.50m or 2.20m |
1800 mm |
| 2000 mm | ||||
| 2100 mm | ||||
| 2200 mm | ||||
| 2400 mm | ||||
| 2500 mm | ||||
| 3000 mm |
Panel-type B (3D view)
| Mesh | Wire thickness | Surface Treatment | Panel width | No.of "V" | Height |
| 76.2x12.7mm |
Horizontal wire:3.0,3.5,4.0mm Vertical wire:4.0mm |
Galvanized & Electrostatic polyester powder coated or hot dipped galvanized |
2.50m or 2.20m |
3 | 1800 mm |
| 3 | 2000 mm | ||||
| 4 | 2100 mm | ||||
| 4 | 2200 mm | ||||
| 4 | 2400 mm | ||||
| 5 | 2500 mm | ||||
| 6 | 3000 mm |
Post
| Type | Profile | Wall thickness | Surface treatment | Length | Rain hat | ||||||||
| RHS Pipe | 80x60mm | 3.00mm | Galvanized & Electrostatic polyester powder coated or hot-dipped galvanized. | Based on the panel height | Plastic or Metal | ||||||||
| C Post | 83x64mm | ||||||||||||
Packaging Details 358 security fence :
- 1. security fence panels have a sponge at the bottom of the pallet to protect the bottom fence panel.
- 2. security fencing has 4 steel corners to strengthen the pallet.
- 3. anti-cut fence panels have a metal plate under the bandage to avoid the bandage destroying the fence panel.
- 4. 358 security fence has the wood plate on the top of the fence panel pallet to avoid the above pallet destroying the under fence panel pallet.
- 5. After packing, the fence panel pallet is beautiful and firm.
